D series(XF200-C/D/E)
Simple, Easy To Operate
Fixed Focus, Clear Image
Lightweight, Well Balanced, IP54 Protection
Quickly Find Problems
Touch Screen And Buttons, Dual Operation Mode
High Resolution, Multiple Options
| Model | XF200-C | XF200-D | XF200-E |
| Detector type | Uncooled FPA, VOX material | ||
| IR Resolution | 160x120 | 256x192 | 384x288 |
| Thermal Sensitivity/NETD | ≤0.05℃@30℃ | ||
| Spectral Range | 7.5~14μm | ||
| Field of View | 56°x42.2° | ||
| Spatial resolution (IFOV) | 6.11mrad | 3.82mrad | 2.54mrad |
| Focus | Fixed | ||
| Focal Length | 2mm | 3.2mm | 4.8mm |
| Focus distance | 1m to infinity | ||
| Image frequency | 25Hz | ||
| Image Display | |||
| Display | 3.5” LCD touch screen | ||
| Display resolution | 320x240 | ||
| Color Palettes | 10 color modes | ||
| Visible camera | 5 million pixels visual camera | ||
| Digital zoom | x1,x2,x4 | ||
| Measurement And Analysis | |||
| Object temperature range | -20℃~+150℃ (low temperature range)/100℃~+650℃ (medium temperature range) | ||
| Temperature measurement accurary | ±4℃ or 4% of readings | ||
| Spot,line and area setting | It can support up to 10 points, 10 boxes and 5 lines at the same time | ||
| Tracking function | Highest temperature spot auto tracking | ||
| Image storage And Transmission | |||
| Storage Media | 32G removable SD card(More than 10,000 infrared images can be stored) | ||
| Thermal image format | .jpg (including full temperature data) | ||
| Thermal video format | .H264 | ||
| WIFI | Support,support preview SD card pictures through WIFI | ||
| Laser Alignment | Support | ||
| Alarm mode | Automatic acousto-optic alarm for set temperature value/above/below | ||
| Power System | |||
| Battery type | Detachable rechargeable lithium battery | ||
| Battery voltage | DC12V | ||
| Battery operating time | Approx. 4 hours at 25°C ambient temperature and typical use | ||
| Charging mode | Two-socket charger or 12V car charger | ||
| Environmental Parameters | |||
| Protection level | IP54 | ||
| Operation temperature | -20℃~ 55℃ | ||
| Physical Characteristics | |||
| Weight | 610g（battery included） | ||
| Size | 245x107x60mm | ||
| Packing List | |||
| Camera | 1 | ||
| Rechargeable lithium battery | 2 | ||
| Charger | 1 | ||
| SD card | 1 | ||
| Card reader | 1 | ||
| U disk | 1 | ||
| Manuals | 1 | ||
| Temperature measurement report | 1 | ||
| Warranty card | 1 | ||
| Certificate of conformity | 1 | ||
| Shockproof equipment box | 1 | ||
Specifications are subject to change without prior notice.
